Bevles Model: PICA70-32INS-AED-1L1 (Insulated) Extra Deep (115V) Single Door Left Hand Hinged Proofing Cabinet

Bevles Model: PICA70-32INS-AED-1L1 (Insulated) Extra Deep (115V) Single Door Left Hand Hinged Proofing Cabinet

by Bevles
Save 7% Save 7%
$5,349.61
$5,349.61 - $5,349.61
$5,349.61
$4,953.34
$4,953.34 - $4,953.34
$4,953.34

This proof box will work for 23 x 33 screens. Aluminum construction with universal extruded pan supports accommodate a variety of pans and screens. Full-length Lexan® door with heavy duty hinges, positive closing latch and perimeter gasket. Bottom mounted electrical unit with separate controls for heat and humidity. “Cast-in” humidity system prevents element burnout and potential injury from accidental contact with exposed heating element. Self-draining feature collects excess moisture into a standard bun pan (not included) below the base of cabinet.

Mobile, full height with insulated top, back & sides.

  • (2) Left Hand Hinged Door

Electrical

120V / 60Hz / 1Ph

Construction:

  • • Body: .063 Formed aluminum
  • • Door: clear Lexan with an extruded aluminum frame
  • • Door latch and hinges: positive action door latch with heavy duty stainless steel hinges • Door gasket: closed cell foam
  • • Base: .125 Formed aluminum
  • • Rear (air duct) panel: .063 Formed aluminum FEATURES
  • • Extra deep to accommodate 32” x 23” pans
  • • Fully insulated top, sides and back on PICA70-32INS-AED
  • • Extruded pan supports accept a variety of pans and screens
  • • Removable heating module PICA70-32INS-AED Insulated NEMA 5-15P
  • • Easy to operate controls feature digital thermostat, variable humidity control and LED display
  • • Maintains uniform temperature/humidity throughout cabinet
  • • 5 quart (4.7 liter) cast water reservoir
  • • “Cast-in” humidity system prevents element burnout from water spills and potential injury from accidental contact with exposed heating element
  • • Temperature adjustable from 60°F (15.6°C) to 120°F (48.9°C)
  • • Self-draining feature collects excess moisture into a standard bun pan (not included) below the base of the cabinet • Completely removable interior components make cleaning quick and easy • Heavy-duty plate casters with 5” neoprene wheels, front two with brakes

 Additional Information

    • Insulated and non-insulated proofing cabinets are available in full, 3/4, half and undercounter size models constructed of aluminum
    • Full size AED models are extra deep at 39" to accommodate pans and screens
    • Universal extruded pan supports will accommodate a wide variety of pans and screens
    • Clear Lexan doors with heavy-duty hinges and positive closing latches with full perimeter gaskets
    • User-friendly, bottom mounted controls feature independent heat and humidity adjustment
    • Temperature range from 60° to 120°F (16° to 49°C) while the water reservoir holds up to 5 quarts (4.7 liters)
    • BevLes "cast-in" humidity system prevents element burnout while providing added safety for the operator
    • Self-draining feature for excess moisture collection below the cabinet
    • Equipped with heavy duty plate swivel casters with 5" (127mm.) neoprene wheels, two with locks
  • SKU: PICA70-32-AED-1L1
